The AxiEco axial fan series from ebm papst can

  • with an air volume of 500 m³/h to 12,500 m³/h,
  • at a counter pressure of 70 Pa to 720 Pa,
  • with a size of 300 mm to 500 mm,
  • from a sound power level of 58 dB(A),
  • at an operating temperature of -25 °C to 60 °C,
  • with a rated voltage of 200 V – 240 V (single-phase) or 380 V – 480 V (three-phase)
  • and at a frequency of 50 or 50/60Hz

be operated.

Please contact us for further technical information or special requirements!

Category:

Product description

The AxiEco axial fans from ebm-papst are characterised by more efficient and quieter operation compared to the HyBlade axial fans.

In refrigeration technology, AxiEco fans resist icing on evaporators and continue to operate constantly at a high level of efficiency. In ventilation and air-conditioning technology, the efficiency of the AxiEco remains high despite increasing back pressure. The AxiEco series is characterised in mechanical engineering by its compact and space-saving design and impresses with increased air performance.

The fans are used in ventilation, air conditioning and refrigeration technology, for example as evaporators, condensers, air heaters, heat pumps, for switch cabinet and generator cooling and in many other areas.

Technical data

Voltage

200 – 480 V

Frequency

50 Hz, 50/60 Hz

Air flow rate

500 – 12.500m³/h

Power consumption

72 – 1.950 W

Counter pressure

70 – 720 Pa

EC technology

Various control and regulation functions

Protective grille

Black plastic-coated (RAL9005), Steel

Wall ring

Black plastic-coated (RAL9005), Galvanised steel plate

Blades

Galvanised sheet metal, PP plastic

Rotor

Black painted surface

Electronics enclosure

Die-cast aluminium, painted grey
