The AxiBlade axial fan series from ebm-papst can

  • with an air volume of 4,500 m³/h to 35,000 m³/h,
  • at a counter pressure of 50 Pa to 380 Pa,
  • with a size of 630 mm to 910 mm,
  • at an operating temperature of -25 °C to 60 °C,
  • with a rated voltage of 380 V – 480 V (three-phase)
  • and at a frequency of 50/60Hz

be operated.

Please contact us for further technical information or special requirements!

Category:

Product informations

The AxiBlade series from ebm-papst offers higher performance and higher efficiency, with a lower noise level, than the proven HyBlade axial fans.

AxiBlade axial fans consist of a FlowGrid, a wall ring, the impeller, a GreenTech EC motor, electronics, a guide vane and a protective grille.

The guide vane increases the air performance and the FlowGrid reduces the noise level (rotary sound). The impeller can increase efficiency thanks to its profiled blade geometry and winglets. This impeller optimisation also reduces the noise level.

With this system, ebm-papst offers a reduction in sound pressure of up to 8 dB(A).

Axiblade axial fans are used in condensers, cooling towers, evaporators, transformer stations, catch grids, heat pumps, oil coolers, process cooling systems and many other areas.

We offer not only standard products, but also customised special versions. These can include, for example, a wider temperature range, customised programming or a special cable and connector design.

The blades are flow-optimized so that they offer higher efficiency at a lower noise level compared to conventional blades. An optional control system can be used to improve the noise values depending on the area of use and application.

In addition, ebm-papst HyBlade axial fans are characterized by optimized efficiency, improved corrosion protection, low weight and environmentally friendly production with a favorable energy balance.

The axial fans are used in almost all sectors for refrigeration, air conditioning and ventilation technology as well as in mechanical engineering, for heat pumps and much more.

We offer not only standard products, but also customised special versions. These can include, for example, a wider temperature range, customised programming or a special cable and connector design.

Voltage

380 – 480 V

Frequency

50/60 Hz

Air flow rate

4.500 – 35.000 m³/h

Power consumption

640 – 3.200 W

Application area

Bis 380 Pa

EC technology

Various control and regulation functions

Protective grille

Black plastic-coated (RAL9005), Steel

Wall ring

Black plastic-coated (RAL9005), Galvanised steel plate

Blades

PP plastic

Rotor

Black painted surface

Electronics enclosure

Die-cast aluminium, black painted
